The High Temperature Drying Machine for Harmless Treatment is particularly suitable for small and medium-sized farms and township waste treatment stations, where processing efficiency and volume reduction are paramount. Drying significantly reduces material volume, lowering subsequent transportation and disposal costs. It also allows for resource recovery, producing dry residue that can be used as fuel or organic fertilizer.
|
Indirect heating |
The jacket is passed through steam/thermal oil, indirect heat transfer |
The material does not come into direct contact with the heat source, the dry residue is high in purity and dust-free |
Animal carcasses, oily kitchen waste (grease needs to be recycled) |
The tail gas treatment is simple and the product has few impurities |
The heating speed is slightly slower and the energy consumption is slightly higher than direct heating |
|
Model |
CMJ-3 |
CMJ-5 |
|
Tank Dimensions (mm) |
φ1400/1600×3062 |
φ1600/1800×4500 |
|
Effective Volume (m³) |
5.2 |
9.6 |
|
Design Pressure (MPa) |
0.45/0.65 |
0.45/0.65 |
|
Design Temperature (160/190) |
160/190 |
160/190 |
|
Processing Capacity (T) |
3.0 |
8.0 |
|
Power (kW) |
37 |
45 |
1. The High Temperature Drying Machine for Harmless Treatment achieves a high volume reduction rate, reducing the volume of dried materials by 60%-80%, significantly reducing subsequent transportation, landfill, or incineration costs.
2. The equipment can offer continuous high temperatures of 120-180°C to kill nearly all pathogenic microorganisms (including heat-resistant Bacillus and viruses), preventing disease transmission and meeting safety standards. For real using example, one of our African partner used this equipment to control swine fever in farms).
3. The dried residue can be used as biomass fuel (replacing coal for boiler heating, reducing energy costs) or as organic fertilizer (high in nitrogen, phosphorus, and potassium, making it suitable for agricultural production), achieving "processing as profit" rather than simply "cost expenditure" and achieving high economic benefits.
4. This harmless treatment equipment features a full PLC control system, allowing for the configuration of parameters such as temperature, time, and stirring speed, eliminating the need for dedicated personnel. Some units support remote monitoring, making it suitable for standardized operations in small and medium-sized facilities (such as township farms).
Shandong Chengming Environmental Technology Co., Ltd., established in 2014 in Zhucheng, Shandong Province, and can offer harmless livestock and poultry waste treatment equipment together with other advanced equipment to global buyers. With 10+ years of professional industry experience, our products are trusted by over 300 slaughterhouses and livestock farms worldwide. We are constantly striving for innovation and research, providing superior products and a one-stop service encompassing R&D, customization, production, installation and commissioning, and after-sales service.
